          SKU: GW/BW BC 316-3-600
          New Zealand's most effective inline effluent filter! For Blackwater, Greywater & Grease Trap systems alike.
          Availability: Out of stock - on backorder and will be dispatched once in stock (4 weeks).
          $430.43 excl GST
          excluding shipping
          i h
          Products

          Servicing Features

          • Easy to operate
          • Quick Job turnaround
          • No messy cleanup or time-consuming cleaning processes



          "The BioCeptor™ actually remains very clean and when it comes to servicing the matter build up just slides off on lifting out the tube! It pretty much cleans itself"



          Operational Features

          • The unique design offers non-mechanical self-cleaning features
          • Effective long term filtering of particles
          • High flow rates maintained between servicing intervals



          "The segments size of the BioCeptor™ on the outer rim allows the collected matter to sloth off over time also keeping itself clean"



          Design Features:

          Construction:

          316 Stainless Steel components. This creates a strong filter that survives performance in a tough environment and cleaning process.

          Complimentary:

          Fits inside industry-standard pipes

          Compliance:

          Designed to satisfy or exceed the requirements of the related building standards.

          Invert:

          The filter seats on the top ledge of a standard PVC Square Junction (TEE) fitting. This determines the dimension from the seat to the highest invert of the outlet pipe (typically 110mm).

          Filtration:

          The star configuration of the filter body is perforated with over 15,600 holes each measuring 3.0mm dia. maximum. (0.11m2)

          Bioceptor 316-3-380 (over 15,600 holes)

          Bioceptor 316-3-470 (under 15,600 holes)

          Bioceptor 316-3-600 (under 15,600 holes)

          Flow-through:

          The interchange plate creates a separation between the filtration screen and the outlet screen.

          The Interchange plate has a full through-opening of 57.7mm diameter.

          Outlet screen:

          The outlet screen has oval holes of 4.5x10.0mm These are larger than the screen to ensure unobstructed pass-through of the screened waste.

          Cleaning:

          The base of the Bioceptor Filter has a simple plate that unscrews from the main filter. This allows you to easily remove the base and flush the filter clean.

          Options:

          Cluster arrangements are available. These are typically 5 filter units in a single housing. Note: The invert configuration remains the same as for a single unit.



          Filter Unit Dimensions

          105mm diameter

          850mm long

          Toilet Unit Weight 1.15kgs

          5 Year Warranty:

          Our Bioceptor Filter is made from 316 stainless steel and designed to withstand normal operational use in a wastewater system.

          Each filter manufactured by Bioceptor NZ Limited, and the housing in the case of CLUSTER filter arrangements, are covered by our manufacturers 5 YEAR LIMITED warranty against manufacturing defects and faults.
